TECHNICAL DATA

SERIES	UNITS	PRFMV 200	PRFMV 250
Model		AVVI 200	AVVI 250
Feed Size (Max)	mm (inch)	58 (2.2)	58 (2.2)
*Capacity	mm (inch)	180 – 320	210 – 370
Rotor Speed	m/s	45 – 70	45 – 70
No.of Parts	mm (inch)	3 / 4 / 5	3 / 4 / 5
Dual Slope Vibrating Screen – 1860 – 4D
Size (W x L)	mm (inch)	1850 x 6000 (72.8 x 236.2)	1850 x 6000 (72.8 x 236.2)
Number of Decks		4	4
ELECTRICAL
Motor Power	kW (hp)	220 (300)	2 x 132 (2 x 180)
Total Power	kW (hp)	250 (330)	290 (390)
Dimension
Transport ( L x W x H )	mm (inch)	13750 x 3600 x 4825 (541.3 x 141.7 x 190)	13750 x 3600 x 4825 (541.3 x 141.7 x 190)
**Weight	Kg (Ton)	36500 (36.5)	38800 (38.8)

*Details may vary based on application
**Weight inclusive of motor & accessories
Note: All the above technical details may vary at any time during engineering process & design development
