TECHNICAL DATA

SERIES	UNITS	PRFMJ 811	PRFMJ 811 V2	PRFMJ 912
Model		AVJ 811 (S)	AVJ 811 V2	AVJ 912
Feed Opening (W x L)	mm (inch)	750 x 1064 (30.0 x 42.0)	840 x 1090 (33 x 42.9)	1250 X 980 (49.2” x 38.5”)
Feed Size (Max.)	mm (inch)	635 (25.0)	715 (28.5)	830 (32.7”)
CSS Range	mm (inch)	75 – 200 (3.0 – 8.0)	75 – 225 (3.0 – 9.0)	100-250 (3.94-9.84)
*Capacity	mm (inch)	150-400	150-500	200-700
Crusher Weight	kg (Ton)	20700 (20.7)	23000 (23.0)	32,000 (32)
Toggle Mechanism	mm (inch)	Single Toggle Type	Single Toggle Type	Single Toggle Type
Construction	mm (inch)	High Grade Carbon Steel with Welded Structure	High Grade Carbon Steel with Welded Structure	High Grade Carbon Steel with Welded Structure
FEEDER
Model		AVGF 1142 V2	AVGF 1142 V2	AVGF 1344 V2
Tray Dimension (W x L)	mm (inch)	1100 x 4200 (43.3 x 165.3)	1100 x 4200 (43.3 x 165.3)	1300 X 4400 (51.2×173.2)
AXLE
Axle Assembley		Double Axle	Double Axle	Triple Axle
ELECTRICAL
Jaw Motor Power	kW (hp)	110 (150)	110 (150)	160 (220)
Total Power	kW (hp)	135 (180)	135 (180)	190 (255)
DIMENSION
Transport ( L x W x H )	mm (inch)	13150 x 3000 x 4750(517.7 x 118.1 x 187.0)	13150 X 3000 X 4950 (517.7 x 118.1 x 194.8 )	13020 X 3400 X 5020 (512.6 x 133.8 x 197.6)
**Weight	Kg	42500	45000	60500
**Weight	(Ton)	(42.5)	(45.0)	(60.5)
